Experience unparalleled convenience with autonomous operation, eliminating the need for constant supervision.
Compact land footprint with a low profile design (Maximum Height ≤ 2500mm).
Start-up to full output in a mere 1.5 hours, providing rapid liquid nitrogen supply.
This innovative nitrogen liquefier utilizes a state-of-the-art cryogenic mixed refrigerant throttle refrigerator. It employs a regenerative multi-component mixed refrigerant throttle cycle. By integrating refrigerants with diverse boiling points, each component aligns with its designated refrigeration zone, efficiently cooling from ambient temperature to -196 °C, achieving the pinnacle of nitrogen liquefaction (-180 °C @ 0.6 MPa).
The system leverages proven technology to ensure safe, reliable, and straightforward maintenance. By using standard refrigerator compressors, the machine allows for easy repairs by refrigeration professionals. Enjoy zero downtime maintenance as the system requires no defrosting.
| Model | WG-STD-05L | WG-STD-1L | WG-STD-3L | WG-STD-5L | WG-STD-10L | WG-STD-20L | WG-STD-30L | WG-STD-50L |
|---|---|---|---|---|---|---|---|---|
| L.Nitrogen Output (L/day) | 12 | 24 | 80 | 120 | 240 | 500 | 720 | 1200 |
| L.Nitrogen Output (L/h) | 0.5 | 1 | 3 | 5 | 10 | 20 | 30 | 50 |
| Power (KW) | 1 | 5 | 8 | 9 | 11 | 25 | 25 | 35 |
| N2 Purity | 99.9% | 99.9% | 99.9% | 99.9% | 99.9% | 99.9% | 99.9% | 99.9% |
| Cooling Form | Air | Air | Air | Air | Water | Water | Water | Water |
