Classification: Biochemical Apparatus
Type: Biochemistry Analyzer
Certification: CE, MSDS, ISO13485
Send Inquiry

Product Description

i

Basic Specifications

Model NO.:CCL-K200
Throughput:Constant 200t/H (Non-ISE)
Warrant:1 Year
Sample Positions:37 Positions
Analysis Method:End-Point, Fixed-Time, Rate, Turbidimetry
Origin:China
★

Product Description

Medical Laboratory Clinic High Quality Fully Automated Clinical Analytical Instrument Biochemical Analysis System

Model: CCL-K200

Automated Clinical Analytical Instrument
⚙

Technical Parameters

Overall Performance Throughput 200 tests/hour
Analysis Method End-point, Fixed-time, Rate(Kinetic), Turbidimetry
Sample & Reagent System Positions 37 Sample / 28 Reagent positions
Volume Sample: 2~70µl / Reagent: 20~350µl
Probe Anti-collision, liquid level detection
Washing Automatic interior and exterior washing
Cooling Refrigerated tray with independent switch
Reaction System Temperature 37±0.2ºC
Cuvettes 48 reusable cuvettes, optical length 6mm
Mixer Probe Independent stirring
STAT Function YES
Optical System Light Source 6V/10W halogen lamp
Wavelength 340, 405, 450, 510, 546, 578, 630, 700nm
Absorbance 0~3.0Abs
Data Management LIS System Bi-direction, support HL7 protocol
Software Windows 7/8/10, 32 or 64 bit
Physical Specs Size (W*D*H) 625*425*460mm
Net Weight 36kg
✚

Medical Equipment Range

We provide comprehensive hospital medical equipment solutions:

  • X-Ray Room: Machine, Processor, Film, Cassette, Lead Clothing
  • Ultrasound: 2D B/W, 2/3/4D Color Ultrasound
  • Laboratory: Chemistry Analyzer, Hematology Analyzer, ELISA Reader, Centrifuge
  • Operation Room: Anesthesia Machine, Ventilator, Operating Table, ECG, Monitor
📷

Product Display

Biochemical Analysis System Detail 1
Biochemical Analysis System Detail 2
Full Analysis Flowchart
?

Frequently Asked Questions

What is the testing speed of the CCL-K200?
The system offers a constant throughput of 200 tests per hour (non-ISE).
What analysis methods are supported by this biochemical analyzer?
It supports End-point, Fixed-time, Rate (Kinetic), and Turbidimetry methods.
How many sample and reagent positions are available?
The instrument is equipped with 37 sample positions and 28 reagent positions with a refrigerated tray.
Does the system support connection to laboratory information systems?
Yes, it features bi-directional LIS system support and is compatible with the HL7 protocol.
What are the power and water requirements?
It requires an AC 220V/110V power supply and consumes less than 5 liters of deionized water per hour.
What is the net weight and size of the unit?
The external size is 625*425*460mm with a net weight of approximately 36kg, making it a compact benchtop solution.
